ASRock B650E PG-ITX WIFI AM5 Mini-ITX DDR5 64 GB Motherboard
Seller | Shipping | Promo | Price |
---|---|---|---|
|
- | - | |
|
- | - |
N/A
|
|
- | - |
N/A
|
|
- | - |
N/A
|
* PC Pro Guide may earn a small commission when you buy through links on our site. (Affiliate disclosure)
* Prices and availability can change without notice. The price and stock status displayed on Amazon at the time you complete your purchase are the ones that apply.
Description
The ASRock B650E PG-ITX WIFI is a Mini-ITX motherboard for AM5. It supports DDR5 memory up to 6200 MT/s (OC).
- ASRock B650E PG-ITX WIFI AM5 Ryzen 7000 AMD B650 6.0 Gb/s DDR5 Mini ITX Motherboard Number of Memory Slots: 2x288pin (DDR5) Audio Chipset: Realtek ALC1220 Audio Channels: 7.1 Channels Max LAN Speed: 2.5Gbps Maximum Memory Supported: 64GB Channel Supported: Dual Channel CPU Type: Supports AMD Ryzen 7000 Series Processors ECC Supported: Yes
Specifications
Manufacturer | ASRock |
---|---|
Model Number | B650E PG-ITX WIFI |
Launch Date | |
CPU Socket | AM5 |
Chipset Model | Intel B650E |
Board Size / Form Factor | Mini-ITX |
Supported Memory Type | DDR5 |
DIMM Slots | 2 |
Maximum RAM Capacity | 64 GB |
Valid DDR4 Speeds | DDR5-4800 / DDR5-5000 / DDR5-5200 / DDR5-5400 / DDR5-5600 / DDR5-5800 / DDR5-6000 / DDR5-6200 (OC) |
ECC Memory Support | No |
Expansion Slots (PCIe) | 1 × PCIe x16 |
PCIe x16 (Qty) | 1 |
PCIe x4 (Qty) | 0 |
PCIe x1 (Qty) | 0 |
M.2 Slot Count | 3 × M.2 |
M.2 Device Compatibility | 2280 - M Key, 2280 - M Key, E-key - E Key |
SATA III Ports | 2 × SATA 6Gbps |
SATA Express Ports | 0 |
Wired Networking (LAN) | |
Onboard Wi-Fi | Yes |
Wi-Fi Standard | 6E (802.11ax, 6 GHz) |
Rear-Panel USB | USB 3.2 Gen2x2, USB 3.2 Gen1 |
Internal USB 3.2 Gen 2x2 Headers | 1 |
Internal USB 3.2 Gen 2 Headers | 0 |
Internal USB 3.2 Gen 1 Headers | 1 |
Internal USB 2.0 Headers | 0 |
NVIDIA SLI | No |
AMD CrossFire | No |
RAID Capability | Yes |
Back-Connect Layout | No |
Manufacturer Part Number (MPN) | B650E PG-ITX WIFI |
SKU Code | B650E PG-ITX WIFI |
GTIN / EAN | 4710483941078 |
