Asus Prime B450M-K AM4 Micro-ATX DDR4 32 GB Motherboard
* PC Pro Guide may earn a small commission when you buy through links on our site. (Affiliate disclosure)
* Prices and availability can change without notice. The price and stock status displayed on Amazon at the time you complete your purchase are the ones that apply.
Description
The Asus Prime B450M-K is a Micro-ATX motherboard for AM4. It supports DDR4 memory up to 3200 MT/s (OC).
- 32GB DDR4-SDRAM
- Micro-ATX Form Factor
- Ports: 1 X PS/2 Keyboard/Mouse, 1 X DVI-D, 1 X D-Sub, 1 X LAN (RJ45), 2 X USB3.1 Gen 2, 4 X USB3.1 Gen 1, 3 X Audio Jacks
- Includes 5X Protection III For Multiple Hardware Safeguards For All-Round Protection
- Backed By A 3 Years Manufacturers Warranty
Specifications
| Manufacturer | ASUS |
|---|---|
| Model Number | PRIME B450M-K 90MB0YP0-M0EAY0 PRIME B450M-K GAMING |
| Launch Date | July 2020 |
| CPU Socket | AMD Socket AM4 |
| Chipset Model | Intel B450 |
| Board Size / Form Factor | Micro-ATX |
| Supported Memory Type | DDR4 |
| DIMM Slots | 2 |
| Maximum RAM Capacity | 32 GB |
| Valid DDR4 Speeds | DDR4-2133 / DDR4-2400 / DDR4-2666 / DDR4-2800 / DDR4-2933 / DDR4-3000 / DDR4-3200 (OC) |
| ECC Memory Support | No |
| Expansion Slots (PCIe) | 1 × PCIe x16, 2 × PCIe x1 |
| PCIe x16 (Qty) | 1 |
| PCIe x4 (Qty) | 0 |
| PCIe x1 (Qty) | 2 |
| M.2 Slot Count | 1 × M.2 |
| M.2 Device Compatibility | 2242 / 2260 / 2280 - M Key |
| SATA III Ports | 4 × SATA 6Gbps |
| SATA Express Ports | 0 |
| Wired Networking (LAN) | |
| Onboard Wi-Fi | No |
| Wi-Fi Standard | |
| Rear-Panel USB | USB 3.2 Gen1, USB 2.0 |
| Internal USB 3.2 Gen 2x2 Headers | 0 |
| Internal USB 3.2 Gen 2 Headers | 0 |
| Internal USB 3.2 Gen 1 Headers | 1 |
| Internal USB 2.0 Headers | 2 |
| NVIDIA SLI | No |
| AMD CrossFire | No |
| RAID Capability | Yes |
| Back-Connect Layout | No |
| Manufacturer Part Number (MPN) | PRIME B450M-K |
| SKU Code | PRIME B450M-K |
| GTIN / EAN | 192876020432 |
