ASUS PRO Q470M-C/CSM LGA1200 Micro-ATX DDR4 128 GB Motherboard
| Seller | Shipping | Promo | Price |
|---|---|---|---|
|
- | - |
N/A
|
|
- | - |
N/A
|
|
- | - |
N/A
|
|
- | - |
N/A
|
* PC Pro Guide may earn a small commission when you buy through links on our site. (Affiliate disclosure)
* Prices and availability can change without notice. The price and stock status displayed on Amazon at the time you complete your purchase are the ones that apply.
Description
The ASUS PRO Q470M-C/CSM is a Micro-ATX motherboard for LGA1200. It supports DDR4 memory up to 2933 MT/s (OC).
- Intel LGA 1200 Socket: Ready For 10Th Gen Intel Core Vpro Processors, Features 4X DDR4, 6X SATA, 2Xdisplayport, DVI/D-Sub, Dual M. 2, Intel I219V, Front Panel USB 3. 2 Gen 1 Type-C
- ASUS-Exclusive Self-Recovering BIOS Technology For Automatic System BIOS Recovery From A Verified Backup
- ASUS CSM Motherboard: ASUS Corporate Stable Model, With Up To 36-Month Supply, EOL Notice & ECN Control
- ASUS Event Log For Capturing And Managing Detailed System Information
- ASUS Control Center Express(ACCE) To Make IT Endpoint Management
- Dedicated LPC Header And Debug Card With LCD Display For Faster Troubleshooting
- Innovative Moisture-Resistant Coating To Protect The Motherboard From Harsh Environments
Specifications
| Manufacturer | ASUS |
|---|---|
| Model Number | PRO Q470M-C/CSM 90MB1380-M0EAYC 90MB1380-M0AAYC |
| Launch Date | May 2020 |
| CPU Socket | LGA1200 |
| Chipset Model | Intel Q470 |
| Board Size / Form Factor | Micro-ATX |
| Supported Memory Type | DDR4 |
| DIMM Slots | 4 |
| Maximum RAM Capacity | 128 GB |
| Valid DDR4 Speeds | DDR4-2133 / DDR4-2400 / DDR4-2666 / DDR4-2800 / DDR4-2933 (OC) |
| ECC Memory Support | No |
| Expansion Slots (PCIe) | 1 × PCIe x16, 1 × PCIe x1 |
| PCIe x16 (Qty) | 1 |
| PCIe x4 (Qty) | 0 |
| PCIe x1 (Qty) | 1 |
| M.2 Slot Count | 3 × M.2 |
| M.2 Device Compatibility | 2242 / 2260 / 2280 / 22110 - M Key, 2242 / 2260 / 2280 - M Key, 2230 - E Key |
| SATA III Ports | 6 × SATA 6Gbps |
| SATA Express Ports | 0 |
| Wired Networking (LAN) | |
| Onboard Wi-Fi | No |
| Wi-Fi Standard | |
| Rear-Panel USB | USB 3.2 Gen2, USB 3.2 Gen1, USB 2.0 |
| Internal USB 3.2 Gen 2x2 Headers | 0 |
| Internal USB 3.2 Gen 2 Headers | 1 |
| Internal USB 3.2 Gen 1 Headers | 1 |
| Internal USB 2.0 Headers | 1 |
| NVIDIA SLI | No |
| AMD CrossFire | No |
| RAID Capability | Yes |
| Back-Connect Layout | No |
| Manufacturer Part Number (MPN) | PRO Q470M-C/CSM |
| SKU Code | PRO Q470M-C/CSM |
| GTIN / EAN | 192876714201 |
