Asus ROG STRIX B860-I GAMING WIFI LGA1851 Mini-ITX DDR5 128 GB Motherboard
* PC Pro Guide may earn a small commission when you buy through links on our site. (Affiliate disclosure)
* Prices and availability can change without notice. The price and stock status displayed on Amazon at the time you complete your purchase are the ones that apply.
Description
The Asus ROG STRIX B860-I GAMING WIFI is a Mini-ITX motherboard for LGA1851. It supports DDR5 memory up to 9066 MT/s (OC).
- ASUS ROG STRIX B860-I GAMING WIFI B860 LGA 1851 mITX Mini-ITX motherboard, Intel Core Ultra Series 2 Ready, Advanced AI ready, 10+1+2+1 stage, DDR5, 2.5G LAN, WiFi7, M.2, Thunderbolt 4, USB Type-C Memory Standard: Up to 9066+MT/s (OC) Number of Memory Slots: 2x288pin (DDR5) Audio Chipset: Realtek ALC1220P PCI Express 5.0 x16: Intel Core Ultra Processors (Series 2) 1 x PCIe 5.0 x16 slot PCI Express 4.0 x16: Intel B860 Chipset M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) Max LAN Speed: 2.5Gbps CPU Type: Intel Core Ultra Processors (Series 2) Maximum Memory Supported: 96GB
Specifications
| Manufacturer | Asus |
|---|---|
| Model Number | ROG STRIX B860-I GAMING WIFI 90MB1JB0-M0AAY0 |
| Launch Date | January 2025 |
| CPU Socket | LGA1851 |
| Chipset Model | Intel B860 |
| Board Size / Form Factor | Mini-ITX |
| Supported Memory Type | DDR5 |
| DIMM Slots | 2 |
| Maximum RAM Capacity | 128 GB |
| Valid DDR4 Speeds | DDR5-4800 / DDR5-9066 (OC) |
| ECC Memory Support | No |
| Expansion Slots (PCIe) | 1 × PCIe x16 |
| PCIe x16 (Qty) | 1 |
| PCIe x4 (Qty) | 0 |
| PCIe x1 (Qty) | 0 |
| M.2 Slot Count | 2 × M.2 |
| M.2 Device Compatibility | 2260 / 2280 - M Key, 2242 / 2260 / 2280 - M Key |
| SATA III Ports | 4 × SATA 6Gbps |
| SATA Express Ports | 0 |
| Wired Networking (LAN) | 2.5GbE LAN |
| Onboard Wi-Fi | Yes |
| Wi-Fi Standard | 7 (802.11be) |
| Rear-Panel USB | USB 3.2 Gen2, USB 3.2 Gen1, USB 2.0 |
| Internal USB 3.2 Gen 2x2 Headers | 0 |
| Internal USB 3.2 Gen 2 Headers | 1 |
| Internal USB 3.2 Gen 1 Headers | 1 |
| Internal USB 2.0 Headers | 1 |
| NVIDIA SLI | No |
| AMD CrossFire | No |
| RAID Capability | Yes |
| Back-Connect Layout | No |
| Manufacturer Part Number (MPN) | ROG STRIX B860-I GAMING WIFI |
| SKU Code | ROG STRIX B860-I GAMING WIFI |
| GTIN / EAN | 197105815995 |
