Asus TUF GAMING X670E-PLUS WIFI AM5 ATX DDR5 192 GB Motherboard
| Seller | Shipping | Promo | Price |
|---|---|---|---|
|
- | - |
N/A
|
|
- | - |
N/A
|
|
- | - |
N/A
|
|
£49.34 | - |
* PC Pro Guide may earn a small commission when you buy through links on our site. (Affiliate disclosure)
* Prices and availability can change without notice. The price and stock status displayed on Amazon at the time you complete your purchase are the ones that apply.
Description
The Asus TUF GAMING X670E-PLUS WIFI is a ATX motherboard for AM5. It supports DDR5 memory up to 6400 MT/s (OC).
- Specification:CPUAMD Socket AM5 for AMD Ryzen 7000 Series Desktop Processors ChipsetAMD X670Memory4 x DIMM, Max. 128GB, DDR5 5600MHz up to 6400MHz(OC) Supports AMD EXTended Profiles for Overclocking (EXPO)Onboard Graphics Outputs1 x DisplayPort1 x HDMI port PCI SlotsAMD Ryzen 7000 Series Desktop Processors: 1 x PCIe 5.0 x16 slot(s)AMD X670 Chipset: 1 x PCIe 4.0 x16 slot (supports x4 mode)1 x PCIe 4.0 x4 slotsStorageTotal supports 4 x M.2 slots and 4 x SATA 6Gb/s portsAMD Ryzen 7000 Series Desktop Processors: M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)AMD X670 Chipset:M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes)M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)Networking1 x Realtek 2.5Gb EthernetWi-Fi 6EBluetoothAudioRealtek S1220A 7.1 Surround Sound High Definition Audio CODECConnectivity1 x USB 3.2 Gen 2x2 port (1 x USB Type-C)4 x USB 3.2 Gen 2 port(s) (3 x Type-A, 1 x USB Type-C)5 x USB 3.2 Gen 1 port(s) (5 x Type-A)1 x DisplayPort1 x HDMI port1 x Realtek 2.5Gb Ethernet port5 x Audio jacks 1 x BIOS FlashBack button Internal PortsFan and Cooling related: 1 x 4-pin CPU Fan header1 x 4-pin CPU OPT Fan header1 x 4-pin AIO Pump header4 x 4-pin Chassis Fan headers1 x W_PUMP+ header(s)Power related: 1 x 24-pin Main Power connector2 x 8-pin +12V Power connectorsStorage related: 4 x M.2 slots (Key M) 4 x SATA 6Gb/s portsUSB: 1 x USB 3.2 Gen 2 connector (supports USB Type-C )1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports3 x USB 2.0 headers support additional 6 USB 2.0 portsMiscellaneous: 3 x Addressable Gen 2 headers1 x AURA RGB header1 x Clear CMOS header1 x COM Port header1 x Front Panel Audio header (AAFP)1 x 20-3 pin System Panel header with Chassis intrude function1 x Thermal Sensor header1 x Thunderbolt headerForm FactorATX Form Factor - 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
Specifications
| Manufacturer | Asus |
|---|---|
| Model Number | TUF GAMING X670E-PLUS WIFI 90MB1BK0-M0AAY0 |
| Launch Date | |
| CPU Socket | AM5 |
| Chipset Model | Intel X670E |
| Board Size / Form Factor | ATX |
| Supported Memory Type | DDR5 |
| DIMM Slots | 4 |
| Maximum RAM Capacity | 192 GB |
| Valid DDR4 Speeds | DDR5-4800 / DDR5-5000 / DDR5-5200 / DDR5-5400 / DDR5-5600 / DDR5-5800 / DDR5-6000 / DDR5-6200 / DDR5-6400 (OC) |
| ECC Memory Support | No |
| Expansion Slots (PCIe) | 2 × PCIe x16, 1 × PCIe x4 |
| PCIe x16 (Qty) | 2 |
| PCIe x4 (Qty) | 1 |
| PCIe x1 (Qty) | 0 |
| M.2 Slot Count | 4 × M.2 |
| M.2 Device Compatibility | 2242 / 2260 / 2280 - M Key, 2242 / 2260 / 2280 / 22110 - M Key, 2242 / 2260 / 2280 - M Key, 2242 / 2260 / 2280 - M Key |
| SATA III Ports | 4 × SATA 6Gbps |
| SATA Express Ports | 0 |
| Wired Networking (LAN) | |
| Onboard Wi-Fi | Yes |
| Wi-Fi Standard | 6E (802.11ax, 6 GHz) |
| Rear-Panel USB | USB 3.2 Gen2, USB 3.2 Gen1 |
| Internal USB 3.2 Gen 2x2 Headers | 0 |
| Internal USB 3.2 Gen 2 Headers | 1 |
| Internal USB 3.2 Gen 1 Headers | 1 |
| Internal USB 2.0 Headers | 0 |
| NVIDIA SLI | No |
| AMD CrossFire | No |
| RAID Capability | Yes |
| Back-Connect Layout | No |
| Manufacturer Part Number (MPN) | TUF GAMING X670E-PLUS WIFI |
| SKU Code | TUF GAMING X670E-PLUS WIFI |
| GTIN / EAN | 195553905732 |
