Description
The Asus X99-E WS is a SSI CEB motherboard for LGA2011-3. It supports DDR4 memory up to 3200 MT/s (OC).
- LGA 2011-v3
- Chipset: Intel X99
- Memory: 8x DDR4-3200(OC)/ 3000(OC)/ 2800(OC)/ 2666(OC)/ 2400(OC)/ 2133 DIMM Slots, Quad-Channel, Non-ECC, Unbuffered, Max Capacity up to 64GB
- Slots: 7x PCI-Express 3.0/2.0 x16 Slots (run at single x16 or dual x16/x16 or triple x16/x16/x16 or quad x16/x16/x16/x16 or seven x16/x8/x8/x8/x16/x8/x8)
- Ports: 14x USB 3.0 Ports (10 rear, 4 at mid-board), 4x USB 2.0 Ports (4 at mid-board), 2x eSATA Ports, 1x Optical S/PDIF Out, 2x RJ45 LAN Ports, Audio I/O Jacks
- Form Factor: CEB, 12.0 x 10.5 inch / 30.5 x 26.7 cm
- Supreme Power Efficiency: Premium Components deliver industry-leading power efficiency
- The leading IO Scalability
- Convenient Maintenance Tool
Specifications
| Manufacturer | Asus |
|---|---|
| Model Number | X99-E WS 90SB04Q0-M0EAY0 |
| Launch Date | October 2014 |
| CPU Socket | LGA2011-3 |
| Chipset Model | Intel X99 |
| Board Size / Form Factor | SSI CEB |
| Supported Memory Type | DDR4 |
| DIMM Slots | 8 |
| Maximum RAM Capacity | 128 GB |
| Valid DDR4 Speeds | DDR4-2133 / DDR4-2400 / DDR4-2666 / DDR4-2800 / DDR4-3000 / DDR4-3200 (OC) |
| ECC Memory Support | No |
| Expansion Slots (PCIe) | 7 × PCIe x16 |
| PCIe x16 (Qty) | 7 |
| PCIe x4 (Qty) | 0 |
| PCIe x1 (Qty) | 0 |
| M.2 Slot Count | 1 × M.2 |
| M.2 Device Compatibility | 2260 / 2280 - M Key |
| SATA III Ports | 8 × SATA 6Gbps |
| SATA Express Ports | 2 |
| Wired Networking (LAN) | |
| Onboard Wi-Fi | No |
| Wi-Fi Standard | |
| Rear-Panel USB | USB 3.2 Gen1, USB 2.0 |
| Internal USB 3.2 Gen 2x2 Headers | 0 |
| Internal USB 3.2 Gen 2 Headers | 0 |
| Internal USB 3.2 Gen 1 Headers | 2 |
| Internal USB 2.0 Headers | 2 |
| NVIDIA SLI | Yes |
| AMD CrossFire | Yes |
| RAID Capability | Yes |
| Back-Connect Layout | No |
| Manufacturer Part Number (MPN) | X99-E WS |
| SKU Code | X99-E WS |
| GTIN / EAN | 886227869107 |
