Asus Z170-PREMIUM LGA1151 ATX DDR4 64 GB Motherboard
| Seller | Shipping | Promo | Price |
|---|---|---|---|
|
- | - | |
|
- | - |
N/A
|
|
- | - |
N/A
|
|
- | - |
N/A
|
* PC Pro Guide may earn a small commission when you buy through links on our site. (Affiliate disclosure)
* Prices and availability can change without notice. The price and stock status displayed on Amazon at the time you complete your purchase are the ones that apply.
Description
The Asus Z170-PREMIUM is a ATX motherboard for LGA1151. It supports DDR4 memory up to 4000 MT/s (OC).
- Socket: LGA 1151
- Chipset: Intel Z170
- Memory: 4x DDR4-4000(OC)/ 3866(OC)/ 3800(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3300(OC)/ 3200(OC)/ 3000(OC)/ 2800(OC)/ 2666(OC)/ 2400(OC)/ 2133(OC) MHz DIMM Slots, Dual Channel, Max Capacity of 64GB
- Slots: 2x PCI-Express 3.0/2.0 x16 Slots (run at x16 or dual at x8), 1x PCI-Express 3.0/2.0 x16 Slot (max. at x4 mode), 4x PCI-Express x1 Slots
- Multi-Graphics: Supports AMD Quad-GPU CrossFireX, 3-Way CrossFireX and NVIDIA Quad-GPU SLI, 2-Way SLI Technology
- SATA: 8x SATA3 Ports, Six Support RAID 0, 1, 5, 10; 2x SATA Express Port
- LAN: Intel I219V and Intel I211-AT Gigabit Ethernet Controller, Wi-Fi 802.11a/b/g/n/ac Wireless LAN (2.4/5GHz); Bluetooth V4.0
- Ports: 4x USB 3.1 Ports (2 Type-A, 2 Type-C), 6x USB 3.0 Ports (2 rear, 4 at mid-board), 6x USB 2.0 Ports (2 rear, 4 at mid-board), 1x HDMI Port, 1x DisplayPort, 2x RJ45 LAN Ports, 1x Optical S/PDIF Out, 1x ASUS Wi-Fi GO! Module, Audio I/O Jacks
Specifications
| Manufacturer | Asus |
|---|---|
| Model Number | Z170-PREMIUM |
| Launch Date | |
| CPU Socket | LGA1151 |
| Chipset Model | Intel Z170 |
| Board Size / Form Factor | ATX |
| Supported Memory Type | DDR4 |
| DIMM Slots | 4 |
| Maximum RAM Capacity | 64 GB |
| Valid DDR4 Speeds | DDR4-2133 / DDR4-2400 / DDR4-2666 / DDR4-2800 / DDR4-3000 / DDR4-3200 / DDR4-3300 / DDR4-3333 / DDR4-3400 / DDR4-3466 / DDR4-3600 / DDR4-3733 / DDR4-3800 / DDR4-3866 / DDR4-4000 (OC) |
| ECC Memory Support | No |
| Expansion Slots (PCIe) | 3 × PCIe x16, 4 × PCIe x1 |
| PCIe x16 (Qty) | 3 |
| PCIe x4 (Qty) | 0 |
| PCIe x1 (Qty) | 4 |
| M.2 Slot Count | 1 × M.2 |
| M.2 Device Compatibility | 2242 / 2260 / 2280 / 22110 - M Key |
| SATA III Ports | 4 × SATA 6Gbps |
| SATA Express Ports | 2 |
| Wired Networking (LAN) | |
| Onboard Wi-Fi | Yes |
| Wi-Fi Standard | 5 |
| Rear-Panel USB | USB 3.2 Gen1, USB 2.0 |
| Internal USB 3.2 Gen 2x2 Headers | 0 |
| Internal USB 3.2 Gen 2 Headers | 0 |
| Internal USB 3.2 Gen 1 Headers | 2 |
| Internal USB 2.0 Headers | 2 |
| NVIDIA SLI | Yes |
| AMD CrossFire | Yes |
| RAID Capability | No |
| Back-Connect Layout | No |
| Manufacturer Part Number (MPN) | Z170-PREMIUM |
| SKU Code | Z170-PREMIUM |
| GTIN / EAN | 889349251072 |
