ASUS Z170 Pro Gaming/AURA LGA1151 ATX DDR4 64 GB Motherboard
| Seller | Shipping | Promo | Price |
|---|---|---|---|
|
- | - | |
|
- | - |
N/A
|
|
- | - |
N/A
|
|
- | - |
N/A
|
* PC Pro Guide may earn a small commission when you buy through links on our site. (Affiliate disclosure)
* Prices and availability can change without notice. The price and stock status displayed on Amazon at the time you complete your purchase are the ones that apply.
Description
The ASUS Z170 Pro Gaming/AURA is a ATX motherboard for LGA1151. It supports DDR4 memory up to 3466 MT/s (OC).
- LGA1151 socket for 6th-generation Intel Core i7 / Core i5 / Core i3, Pentium and Celeron processors
- Dual DDR4 3466 (OC) support
- True gaming aesthetics: 3D-printing friendly and Aura RGB lighting
- Easy and stable overclocking: Pro Clock technology, 5-Way Optimisation and 2nd-generation T-Topology
- SupremeFX: Flawless audio that makes you part of the game
- Sonic Radar ll: Scan and detect your enemies to dominate
- Top-speed protected networking: Intel Gigabit Ethernet, LANGuard and GameFirst IV
- RAMCache: Speed up your game loads
- Ultra-speedy transfers for faster gaming: USB 3.1 Type-A/C & M.2
- Gamer’s Guardian: SafeSlot, highly-durable components and smart DIY features
Specifications
| Manufacturer | ASUS |
|---|---|
| Model Number | Z170 Pro Gaming/AURA |
| Launch Date | |
| CPU Socket | LGA1151 |
| Chipset Model | Intel Z170 |
| Board Size / Form Factor | ATX |
| Supported Memory Type | DDR4 |
| DIMM Slots | 4 |
| Maximum RAM Capacity | 64 GB |
| Valid DDR4 Speeds | DDR4-2133 / DDR4-2400 / DDR4-2666 / DDR4-2800 / DDR4-2933 / DDR4-3000 / DDR4-3200 / DDR4-3333 / DDR4-3400 / DDR4-3466 (OC) |
| ECC Memory Support | No |
| Expansion Slots (PCIe) | 3 × PCIe x16, 3 × PCIe x1 |
| PCIe x16 (Qty) | 3 |
| PCIe x4 (Qty) | 0 |
| PCIe x1 (Qty) | 3 |
| M.2 Slot Count | 1 × M.2 |
| M.2 Device Compatibility | 2242 / 2260 / 2280 / 22110 - M Key |
| SATA III Ports | 6 × SATA 6Gbps |
| SATA Express Ports | 0 |
| Wired Networking (LAN) | |
| Onboard Wi-Fi | No |
| Wi-Fi Standard | |
| Rear-Panel USB | USB 3.2 Gen1, USB 2.0 |
| Internal USB 3.2 Gen 2x2 Headers | 0 |
| Internal USB 3.2 Gen 2 Headers | 0 |
| Internal USB 3.2 Gen 1 Headers | 1 |
| Internal USB 2.0 Headers | 3 |
| NVIDIA SLI | Yes |
| AMD CrossFire | Yes |
| RAID Capability | Yes |
| Back-Connect Layout | No |
| Manufacturer Part Number (MPN) | Z170 Pro Gaming/AURA |
| SKU Code | Z170 Pro Gaming/AURA |
| GTIN / EAN | 889349467596 |
Price History (last 12 months)
Plots available price points within the past 12 months.
