EVGA X570 FTW WiFi AM4 ATX DDR4 128 GB Motherboard
* PC Pro Guide may earn a small commission when you buy through links on our site. (Affiliate disclosure)
* Prices and availability can change without notice. The price and stock status displayed on Amazon at the time you complete your purchase are the ones that apply.
Description
The EVGA X570 FTW WiFi is a ATX motherboard for AM4. It supports DDR4 memory up to 4600 MT/s (OC).
- AMD X570 Chipset, Supports AMD Ryzen 5000 and 3000 Series processors for the AMD AM4 socket
- PCIe Gen4, M.2 Gen4, ATX Form Factor, 15 Phase PWM, Metal Reinforced PCIe Slots, NVIDIA SLI Ready, Preinstalled rear I/O cover
- 4 DIMM Dual-Channel supports up to 128GB 4600+ MHz, 3 USB 3.2 Gen2 Ports (2x Type A, 1x Type-C), DP 1.4/HDMI 2.0
- 8 SATA 6Gb/s, 2x M.2 Key-M 110mm, 1x M.2 Key-E 32mm with installed Wi-Fi 6/BT 5.2, Intel Gigabit NIC
- Onboard ARGB lighting + 2x ARGB / 2x RGB Headers fully customizable through EVGA ELEET X1
Specifications
| Manufacturer | EVGA |
|---|---|
| Model Number | 121-VR-A577-KR X570 FTW WIFI |
| Launch Date | January 2022 |
| CPU Socket | AMD Socket AM4 |
| Chipset Model | Intel X570 |
| Board Size / Form Factor | ATX |
| Supported Memory Type | DDR4 |
| DIMM Slots | 4 |
| Maximum RAM Capacity | 128 GB |
| Valid DDR4 Speeds | DDR4-2133 / DDR4-2400 / DDR4-2666 / DDR4-2800 / DDR4-3000 / DDR4-3200 / DDR4-3466 / DDR4-3600 / DDR4-3733 / DDR4-4000 / DDR4-4133 / DDR4-4600 (OC) |
| ECC Memory Support | No |
| Expansion Slots (PCIe) | 2 × PCIe x16 |
| PCIe x16 (Qty) | 2 |
| PCIe x4 (Qty) | 0 |
| PCIe x1 (Qty) | 0 |
| M.2 Slot Count | 3 × M.2 |
| M.2 Device Compatibility | 2242 / 2260 / 2280 / 22110 - M Key, 2242 / 2260 / 2280 / 22110 - M Key, 2230 - E Key |
| SATA III Ports | 8 × SATA 6Gbps |
| SATA Express Ports | 0 |
| Wired Networking (LAN) | |
| Onboard Wi-Fi | Yes |
| Wi-Fi Standard | 6 (802.11ax) |
| Rear-Panel USB | USB 3.2 Gen1, USB 2.0 |
| Internal USB 3.2 Gen 2x2 Headers | 0 |
| Internal USB 3.2 Gen 2 Headers | 0 |
| Internal USB 3.2 Gen 1 Headers | 1 |
| Internal USB 2.0 Headers | 2 |
| NVIDIA SLI | Yes |
| AMD CrossFire | No |
| RAID Capability | Yes |
| Back-Connect Layout | No |
| Manufacturer Part Number (MPN) | 121-VR-A577-KR |
| SKU Code | 121-VR-A577-KR |
| GTIN / EAN | 843368071738 |
