GIGABYTE A620I AX AM5 Mini-ITX DDR5 96 GB Motherboard
* PC Pro Guide may earn a small commission when you buy through links on our site. (Affiliate disclosure)
* Prices and availability can change without notice. The price and stock status displayed on Amazon at the time you complete your purchase are the ones that apply.
Description
The GIGABYTE A620I AX is a Mini-ITX motherboard for AM5. It supports DDR5 memory up to 6400 MT/s (OC).
- AMD AM5 Socket: Supports AMD Ryzen 7000 Series Processors
- Dual Channel DDR5: 2*SMD DIMMs with AMD EXPO & Intel XMP Memory Module Support
- Unparalleled Performance: 5+2+1 Phases Digital VRM Solution
- EZ-Latch: PCIe x16 Slot with a Quick Release & Screwless Design
- Fast Networking: Wi-Fi 6E 802.11ax & 2.5GbE LAN
- Fine Tuning Features: RGB FUSION, Supports Addressable LED & RGB LED Strips, Smart Fan 6, Q-Flash Plus
Specifications
| Manufacturer | Gigabyte |
|---|---|
| Model Number | A620I AX |
| Launch Date | June 2023 |
| CPU Socket | AM5 |
| Chipset Model | Intel A620 |
| Board Size / Form Factor | Mini-ITX |
| Supported Memory Type | DDR5 |
| DIMM Slots | 2 |
| Maximum RAM Capacity | 96 GB |
| Valid DDR4 Speeds | DDR5-4400 / DDR5-4800 / DDR5-5200 / DDR5-5600 / DDR5-6000 / DDR5-6200 / DDR5-6400 (OC) |
| ECC Memory Support | No |
| Expansion Slots (PCIe) | 1 × PCIe x16 |
| PCIe x16 (Qty) | 1 |
| PCIe x4 (Qty) | 0 |
| PCIe x1 (Qty) | 0 |
| M.2 Slot Count | 1 × M.2 |
| M.2 Device Compatibility | 2280 - M Key |
| SATA III Ports | 2 × SATA 6Gbps |
| SATA Express Ports | 0 |
| Wired Networking (LAN) | 2.5GbE LAN |
| Onboard Wi-Fi | Yes |
| Wi-Fi Standard | 6E (802.11ax, 6 GHz) |
| Rear-Panel USB | USB 3.2 Gen2, USB 3.2 Gen1, USB 2.0 |
| Internal USB 3.2 Gen 2x2 Headers | 0 |
| Internal USB 3.2 Gen 2 Headers | 1 |
| Internal USB 3.2 Gen 1 Headers | 1 |
| Internal USB 2.0 Headers | 1 |
| NVIDIA SLI | No |
| AMD CrossFire | No |
| RAID Capability | Yes |
| Back-Connect Layout | No |
| Manufacturer Part Number (MPN) | A620I AX |
| SKU Code | A620I AX |
| GTIN / EAN | 889523038376 |
