Description
The Gigabyte GA-B250-HD3 is a ATX motherboard for LGA1151. It supports DDR4 memory up to 2400 MT/s (OC).
- Supports 7th/6th Generation Intel Core Processors
- Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs
- 2-Way Crossfire Multi-Graphics Support
- Ultra-Fast M.2 with Pie Gen3 x4 & SATA interface
- Intel Octane Memory Ready
Specifications
| Manufacturer | Gigabyte |
|---|---|
| Model Number | GA-B250-HD3 |
| Launch Date | January 2017 |
| CPU Socket | LGA1151 |
| Chipset Model | Intel B250 |
| Board Size / Form Factor | ATX |
| Supported Memory Type | DDR4 |
| DIMM Slots | 4 |
| Maximum RAM Capacity | 64 GB |
| Valid DDR4 Speeds | DDR4-2133 / DDR4-2400 (OC) |
| ECC Memory Support | No |
| Expansion Slots (PCIe) | 2 × PCIe x16, 2 × PCIe x1 |
| PCIe x16 (Qty) | 2 |
| PCIe x4 (Qty) | 0 |
| PCIe x1 (Qty) | 2 |
| M.2 Slot Count | 1 × M.2 |
| M.2 Device Compatibility | 2242 / 2260 / 2280 / 22110 - M Key |
| SATA III Ports | 6 × SATA 6Gbps |
| SATA Express Ports | 1 |
| Wired Networking (LAN) | |
| Onboard Wi-Fi | No |
| Wi-Fi Standard | |
| Rear-Panel USB | USB 3.2 Gen1, USB 2.0 |
| Internal USB 3.2 Gen 2x2 Headers | 0 |
| Internal USB 3.2 Gen 2 Headers | 0 |
| Internal USB 3.2 Gen 1 Headers | 1 |
| Internal USB 2.0 Headers | 2 |
| NVIDIA SLI | No |
| AMD CrossFire | Yes |
| RAID Capability | No |
| Back-Connect Layout | No |
| Manufacturer Part Number (MPN) | GA-B250-HD3 |
| SKU Code | GA-B250-HD3 |
| GTIN / EAN | 889523008393 |
