Gigabyte GA-Z170MX-Gaming 5 LGA1151 Micro-ATX DDR4 64 GB Motherboard
| Seller | Shipping | Promo | Price |
|---|---|---|---|
|
- | - | |
|
- | - |
N/A
|
|
- | - |
N/A
|
|
- | - |
N/A
|
* PC Pro Guide may earn a small commission when you buy through links on our site. (Affiliate disclosure)
* Prices and availability can change without notice. The price and stock status displayed on Amazon at the time you complete your purchase are the ones that apply.
Description
The Gigabyte GA-Z170MX-Gaming 5 is a Micro-ATX motherboard for LGA1151. It supports DDR4 memory up to 3466 MT/s (OC).
- LGA1151, Supports 7th/ 6th Generation Intel Core Processors
- Dual channel DDR4, 4 DIMMs and also contains HDMI port,Displayport for Video Output.
- Intel USB 3.1 with USB type-C - the world’s next universal connector
- 3-Way graphics support with exclusive ultra durable metal shielding over the PCIe slots
- PCIe Gen3 x4 M.2 connector with up to 32Gb/s data transfer (PCIe & SATA SSD support)
- 3 SATA Express Connectors for up to 16Gb/s data transfer
Specifications
| Manufacturer | Gigabyte |
|---|---|
| Model Number | GA-Z170MX-Gaming 5 |
| Launch Date | September 2015 |
| CPU Socket | LGA1151 |
| Chipset Model | Intel Z170 |
| Board Size / Form Factor | Micro-ATX |
| Supported Memory Type | DDR4 |
| DIMM Slots | 4 |
| Maximum RAM Capacity | 64 GB |
| Valid DDR4 Speeds | DDR4-2133 / DDR4-2400 / DDR4-2666 / DDR4-2800 / DDR4-3000 / DDR4-3200 / DDR4-3300 / DDR4-3333 / DDR4-3400 / DDR4-3466 (OC) |
| ECC Memory Support | No |
| Expansion Slots (PCIe) | 3 × PCIe x16, 1 × PCIe x1 |
| PCIe x16 (Qty) | 3 |
| PCIe x4 (Qty) | 0 |
| PCIe x1 (Qty) | 1 |
| M.2 Slot Count | 1 × M.2 |
| M.2 Device Compatibility | 2242 / 2260 / 2280 - M Key |
| SATA III Ports | 0 × SATA 6Gbps |
| SATA Express Ports | 3 |
| Wired Networking (LAN) | |
| Onboard Wi-Fi | No |
| Wi-Fi Standard | |
| Rear-Panel USB | USB 3.2 Gen1, USB 2.0 |
| Internal USB 3.2 Gen 2x2 Headers | 0 |
| Internal USB 3.2 Gen 2 Headers | 0 |
| Internal USB 3.2 Gen 1 Headers | 2 |
| Internal USB 2.0 Headers | 2 |
| NVIDIA SLI | Yes |
| AMD CrossFire | Yes |
| RAID Capability | Yes |
| Back-Connect Layout | No |
| Manufacturer Part Number (MPN) | GA-Z170MX-Gaming 5 |
| SKU Code | GA-Z170MX-Gaming 5 |
| GTIN / EAN | 783627201837 |
