GIGABYTE TRX50 AERO D sTR5 EATX DDR5 1024 GB Motherboard
* PC Pro Guide may earn a small commission when you buy through links on our site. (Affiliate disclosure)
* Prices and availability can change without notice. The price and stock status displayed on Amazon at the time you complete your purchase are the ones that apply.
Description
The GIGABYTE TRX50 AERO D is a EATX motherboard for sTR5. It supports DDR5 memory up to 7800 MT/s (OC).
- AMD sTR5 Socket: Supports AMD Ryzen Threadripper PRO 7000 Series Processors
- Power Design: 16+8+4 Phases Digital VRM Solution
- DDR5 Compatible: 4*SMD R-DIMMs with AMD Expo & Intel XMP Support
- Cutting-Edge Thermal Design: VRM Thermal Armor, M.2 Thermal Guard
- Next Gen Connectivity: Dual USB4 Type-C, PCIe 5.0
- EZ-Latch: PCIe 5.0 & M.2 Connectors with a Quick Release & Screwless Design
- Fast Networking: 10GbE + 2.5GbE Dual LAN and Wi-Fi 7
Specifications
| Manufacturer | GIGABYTE |
|---|---|
| Model Number | TRX50 AERO D |
| Launch Date | |
| CPU Socket | sTR5 |
| Chipset Model | TRX50 |
| Board Size / Form Factor | EATX |
| Supported Memory Type | DDR5 |
| DIMM Slots | 4 |
| Maximum RAM Capacity | 1024 GB |
| Valid DDR4 Speeds | DDR5-4800 / DDR5-5000 / DDR5-5200 / DDR5-5400 / DDR5-5600 / DDR5-5800 / DDR5-6000 / DDR5-6200 / DDR5-6400 / DDR5-6600 / DDR5-6800 / DDR5-7000 / DDR5-7200 / DDR5-7400 / DDR5-7600 / DDR5-7800 (OC) |
| ECC Memory Support | Yes * ECC memory support also depends on the CPU memory controller |
| Expansion Slots (PCIe) | 3 × PCIe x16 |
| PCIe x16 (Qty) | 3 |
| PCIe x4 (Qty) | 0 |
| PCIe x1 (Qty) | 0 |
| M.2 Slot Count | 4 × M.2 |
| M.2 Device Compatibility | 2280 / 25110 - M Key, 2280 / 25110 - M Key, 2280 / 25110 - M Key, 2280 - M Key |
| SATA III Ports | 8 × SATA 6Gbps |
| SATA Express Ports | 0 |
| Wired Networking (LAN) | 2.5GbE LAN |
| Onboard Wi-Fi | Yes |
| Wi-Fi Standard | 7 (802.11be) |
| Rear-Panel USB | USB 3.2 Gen2x2, USB 3.2 Gen1, USB 2.0 |
| Internal USB 3.2 Gen 2x2 Headers | 1 |
| Internal USB 3.2 Gen 2 Headers | 0 |
| Internal USB 3.2 Gen 1 Headers | 1 |
| Internal USB 2.0 Headers | 2 |
| NVIDIA SLI | No |
| AMD CrossFire | No |
| RAID Capability | Yes |
| Back-Connect Layout | No |
| Manufacturer Part Number (MPN) | TRX50 AERO D |
| SKU Code | TRX50 AERO D |
| GTIN / EAN | 889523040560 |
