Gigabyte Z490 AORUS XTREME LGA1200 EATX DDR4 128 GB Motherboard
* PC Pro Guide may earn a small commission when you buy through links on our site. (Affiliate disclosure)
* Prices and availability can change without notice. The price and stock status displayed on Amazon at the time you complete your purchase are the ones that apply.
Description
The Gigabyte Z490 AORUS XTREME is a EATX motherboard for LGA1200. It supports DDR4 memory up to 5000 MT/s (OC).
- Supports 10Th Gen Intel Core Processors
- 16 Phases Digital VRM With 90A Smart Power Stage
- Next Generations VRM Cooling Fins Array And Direct Touch Heatpipe With Nanocarbon Coating
- Nanocarbon Baseplate
- Shielded Xtreme Memory Design With Tantalum Polymer Capacitors Array
- Dual Channel Non-ECC Unbuffered DDR4, 4 Dimms
- AQUANTIA 10Gbe LAN + Intel 2.5 Gbe LAN
- 3X M.2 AORUS Next Generation Thermal Guard
- Intel Wifi 6 And Bluetooth 5 2X2 With AORUS Antennas
- AMP UP Audio ALC1220-VB2 With ESS Sabre ES9018K2M Rear Audio DAC And ESS Sabre ES9218 Front Audio DAC
Specifications
| Manufacturer | Gigabyte |
|---|---|
| Model Number | Z490 AORUS XTREME |
| Launch Date | May 2020 |
| CPU Socket | LGA1200 |
| Chipset Model | Intel Z490 |
| Board Size / Form Factor | EATX |
| Supported Memory Type | DDR4 |
| DIMM Slots | 4 |
| Maximum RAM Capacity | 128 GB |
| Valid DDR4 Speeds | DDR4-2133 / DDR4-2400 / DDR4-2666 / DDR4-2800 / DDR4-2933 / DDR4-3000 / DDR4-3200 / DDR4-3300 / DDR4-3333 / DDR4-3400 / DDR4-3466 / DDR4-3600 / DDR4-3666 / DDR4-3733 / DDR4-3800 / DDR4-3866 / DDR4-4000 / DDR4-4133 / DDR4-4266 / DDR4-4300 / DDR4-4400 / DDR4-4500 / DDR4-4600 / DDR4-4700 / DDR4-4800 / DDR4-5000 (OC) |
| ECC Memory Support | No |
| Expansion Slots (PCIe) | 3 × PCIe x16 |
| PCIe x16 (Qty) | 3 |
| PCIe x4 (Qty) | 0 |
| PCIe x1 (Qty) | 0 |
| M.2 Slot Count | 4 × M.2 |
| M.2 Device Compatibility | 2242 / 2280 / 22110 - M Key, 2242 / 2280 / 22110 - M Key, 2242 / 2260 / 2280 / 22110 - M Key, 2230 - E Key |
| SATA III Ports | 6 × SATA 6Gbps |
| SATA Express Ports | 0 |
| Wired Networking (LAN) | GbE LAN |
| Onboard Wi-Fi | Yes |
| Wi-Fi Standard | 6 (802.11ax) |
| Rear-Panel USB | USB 3.2 Gen2, USB 3.2 Gen1, USB 2.0 |
| Internal USB 3.2 Gen 2x2 Headers | 0 |
| Internal USB 3.2 Gen 2 Headers | 1 |
| Internal USB 3.2 Gen 1 Headers | 1 |
| Internal USB 2.0 Headers | 1 |
| NVIDIA SLI | Yes |
| AMD CrossFire | Yes |
| RAID Capability | Yes |
| Back-Connect Layout | No |
| Manufacturer Part Number (MPN) | Z490 AORUS XTREME |
| SKU Code | Z490 AORUS XTREME |
| GTIN / EAN | 889523021491 |
Price History (last 12 months)
Plots available price points within the past 12 months.
