Intel BOXDQ45EK LGA775 Mini-ITX DDR2 4 GB Motherboard
* PC Pro Guide may earn a small commission when you buy through links on our site. (Affiliate disclosure)
* Prices and availability can change without notice. The price and stock status displayed on Amazon at the time you complete your purchase are the ones that apply.
Description
The Intel BOXDQ45EK is a Mini-ITX motherboard for LGA775. It supports DDR2 memory up to 800 MT/s (OC).
- Form Factor Mini ITX
- 1x PCIeX1, 4x SATA, 1xeSATA, 2xDIMM
- Max Bus Speed 1333 MHz
- Supported RAM Technology DDR2
- Max RAM: 8 GB
Specifications
| Manufacturer | Intel |
|---|---|
| Model Number | BOXDQ45EK |
| Launch Date | |
| CPU Socket | LGA775 |
| Chipset Model | Intel Q45 |
| Board Size / Form Factor | Mini-ITX |
| Supported Memory Type | DDR2 |
| DIMM Slots | 2 |
| Maximum RAM Capacity | 4 GB |
| Valid DDR4 Speeds | DDR4-667 / DDR4-800 (OC) |
| ECC Memory Support | No |
| Expansion Slots (PCIe) | 1 × PCIe x1 |
| PCIe x16 (Qty) | 0 |
| PCIe x4 (Qty) | 0 |
| PCIe x1 (Qty) | 1 |
| M.2 Slot Count | 0 × M.2 |
| M.2 Device Compatibility | |
| SATA III Ports | 0 × SATA 6Gbps |
| SATA Express Ports | 0 |
| Wired Networking (LAN) | |
| Onboard Wi-Fi | No |
| Wi-Fi Standard | |
| Rear-Panel USB | USB 2.0 |
| Internal USB 3.2 Gen 2x2 Headers | 0 |
| Internal USB 3.2 Gen 2 Headers | 0 |
| Internal USB 3.2 Gen 1 Headers | 0 |
| Internal USB 2.0 Headers | 2 |
| NVIDIA SLI | No |
| AMD CrossFire | No |
| RAID Capability | Yes |
| Back-Connect Layout | No |
| Manufacturer Part Number (MPN) | BOXDQ45EK |
| SKU Code | BOXDQ45EK |
| GTIN / EAN | 675900942073 |
