MSI MPG B650 CARBON WIFI

The MSI MPG B650 CARBON WIFI is a ATX motherboard for AM5. It supports DDR5 memory up to 6600 MT/s (OC).

• AMD Socket AM5 for AMD Ryzen 7000 Series Desktop Processors ChipsetAMD B650Memory4 x DIMM, Max. 128GB, DDR5 5200MHz upto 6600MHz (OC) Supports AMD EXTended Profiles for Overclocking (EXPO)Onboard Graphics Outputs1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz1 x DisplayPortPCI Slots2x PCI-E x16 slot1x PCI-E x1 slotPCI_E1 PCIe 4.0 supports up to x16 (From CPU)PCI_E2 PCIe 4.0 supports up to x4 (From CPU)PCI_E3 PCIe 3.0 supports up to x1 (From Chipset)StorageTotal supports 4 x M.2 slots and 6 x SATA 6Gb/s portsM.2_1 (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devicesM.2_2 (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devicesM.2_3 (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devicesM.2_4 (From Chipset) supports up to PCIe 4.0 x4 , supports 22110/2280/2260 devicesNetworking1 x 2.5Gb Ethernet WIFI 6EBluetoothAudioRealtek ALC4080 CodecConnectivityClear CMOS / Flash BIOSDisplay Port2.5G LAN2x USB 2.0 (Type-A)HDMI4x USB 3.2 Gen 2 10Gbps (Type-A)3x USB 3.2 Gen 2 10Gbps (Type-A)USB 3.2 Gen 2x2 20Gbps (Type-C)Wi-Fi / Bluetooth Optical S/PDIF OutInternal Ports1x Power Connector(ATX_PWR)2x Power Connector(CPU_PWR)1x CPU Fan1x Pump Fan5x System Fan2x Front Panel (JFP)1x Chassis Intrusion (JCI)1x Front Audio (JAUD)1x Tuning Controller connector(JDASH)3x Addressable V2 RGB LED connector (JARGB_V2)1x RGB LED connector(JRGB)1x TPM pin header(Support TPM 2.0)4x USB 2.02x USB 3.2 Gen1 Type A1x USB 3.2 Gen2 Type CForm FactorATX Form Factor; 30.5cm x 24.4cm
